Size: 166*164.2*52mm
CPU: RK3588, Octa-Core, main frequency is up to 2.4GHz
GPU: Quad-core Mali-G610 MP4 High-performance GPU
RAM/Storage: Standard 2G / Standard 32G (16G/64G optional)
Built-in ROM: 2KB EEPROM（Not included by default, optional）

Product Introduction

1.1   Scope Of Application

AIBoX-3588D is based on Rockchip RK3588 platform. It has ultra-high AI processing capability of floating point arithmetic and supports multi-channel video and image intelligent analysis. Industrial-grade configuration, dust, shock and high temperature resistance, easily adapt to the harsh deployment environment. Lightweight size can adapt to various terminal forms, with a rich expansion interface. It can be widely used in smart city, security, retail, robotics and industrial Internet, live streaming machine, Arm computer, smart display, edge computing and AIoT solutions, Arm server, high performance tablet PC, and multiple applications requiring multiple cameras and displays, and other AI terminal fields.

1.2   Product Overview

The AIBoX-3588D edge computing box adopts RockChip RK3588 octa-core (4×Cortex-A76+4×Cortex-A55) 64-bit super CPU with built-in 6Tops independent NPU and 8nm advanced manufacturing process with main frequency up to 2.4GHz. With quad-core Mali-G610 MP4 GPU, it supports up to 8K@60fps H.265/VP9 video decoding and 8K@30fps H.265/H.264 video encoding, and supports simultaneous encoding and decoding, up to 32 channels 1080P@30fps decoding and 16 channels 1080P@30fps encoding. Powerful video coding and decoding capability can make the picture high-definition presentation and more detailed picture quality. Stronger performance, faster speed and richer interfaces. It is your best choice for human-computer interaction, intelligent terminals, and industrial control projects.

1.3   Product Feature

l  RK3588 super CPU, equipped with Android 12.0 system, faster speed and stronger performance.

l  RAM and ROM can be configured according to customer needs.

l  Support WIFI6+BT5.0, dual antennas.

l  Dual network port design, supporting dual 10/100/1000M Ethernet.

l  Built in PCI-E 4G module, support HUAWEI, ZTE, LongShang and other PCI-E 4G modules, support internet access and phone calls.

l  Built-in standard SATA chassis to support SATA hard drives.

l  Multiple HDMI inputs and outputs, can support 3 HDMI outputs (3840x2160@60Hz). 2 HDMI inputs, up to 2160p@60 Hz.

l  Support a variety of interfaces, including HDMI, USB interface, 232 serial port, 485 interface, Ethernet, GPIO interface, CAN interface, LINE OUT/IN, etc.

l  High definition. Support 3840x2160@60Hz decoding.

l  Two function buttons (1 power button, 1 user button)

l  Support Android system customization, provide system call interface API reference code.
