Size: 196*106*30mm
CPU: RK3288, quad-core, maximum frequency1.8 GHz，Android 5.1/ 7.1
GPU: ARM Mali-T764 GPU High-performance GPU
Memory/storage: Standard 2G(4G optional)/Standard 16G(8/32/64G optional)
Built-in ROM: 2KB EEPROM(not included by default, optional)

Product Introduction

Features

◆      RAM and ROM can be configured according to customer needs.

◆      Support 12V power input.

◆      Support HDMI output, maximum support 3840x2160 4K decoding, support HDMI 4K dot screen.

◆      Support network port, WIFI, Bluetooth, built-in PCI-E 4G interface. Support a variety of PCI-E 4G modules such as Huawei, ZTE and Longshang, and supports Internet access.

◆      Rich extension interface, 2 USB ports(1*USB OTG,1*USB HOST).

◆      Multiple function keys（1*power button，1*upgrade uboot button，1*customizable keys）.

◆      Support Android system customization, provide system call interface API reference code, perfect support customer upper application APP development.

◆     Perfect support for infrared, optical, capacitive, resistive, touch film and other mainstream touch screen, support non driver touch screen HID configuration without debugging.

Product hardware indicators

The Main Product Hardware Index

Size

196*106*30mm

CPU

RK3288, quad-core, maximum frequency1.8 GHz，Android 5.1/ 7.1

GPU

ARM Mali-T764 GPU High-performance GPU

Memory/storage

Standard 2G(4G optional)/Standard 16G(8/32/64G optional)

Built-in ROM

2KB EEPROM(not included by default, optional)

HD output

1, support 1080P@120Hz, 4kx2k@60Hz output
